inverted bucket trap
2022 C
The trap shall be of the inverted bucket type, designed for use with a 360° universal connector, we can install the model 2022C Inverted Bucket steam trap in any piping configuration to achieve very good efficiency and long service life. The reliability of the trap is also ensured, due to the operating principle of the inverted bucket and the benefits of an all-stainless-steel construction. The prominent features of IB 2022C includes,
- Sealed and tamper-proof package
- Compact and lightweight trap
- Continuous air venting
- The ability to withstand freeze-ups without any damage
- Exceptionally corrosion-resistant workmanship
Maximum Operating Conditions
Maximum allowable pressure (vessel design):
Model 2022
650 psig @ 600°F (45 bar @ 315°C)
627 psig @ 700°F (43 bar @ 371°C)
600 psig @ 800°F (41 bar @ 427°C)
